FiiO : M9

The Ultimate in Versatility

Portable High-Resolution Audio Player

Bring out the best in your computer with USB DAC functionality

The M9 can be used as an asynchronous USB DAC with both Macs and Windows PCs. With Mac computers, you can just plug-and-play the M9 with no drivers needed. With Windows PCs, a simple install of drivers by FiiO is needed. The M9 can also act as your computer’s Bluetooth transmitter – simply hook the M9 up to your computer as a USB DAC, and then have the player transmit Bluetooth audio to your headset!

With the M9, you can get your music from wherever, whenever. Don’t want to deal with wires when transferring your songs over? Use Wi-Fi on the M9. Want to listen to your music on your computer? Do so with DLNA without having to worry about space on the M9. Want to discover new music on streaming services? The built-in streaming apps have you covered.

Get your music from wherever and whenever

*Can install whitelisted third-party music streaming apps

Built-in dedicated FPGA with DSD128 hardware decoding

Inside the M9 is a high-performance A3P030 FPGA, responsible for ensuring your music (whatever sample rate) is played back accurately by stabilizing digital clock signals. The FPGA also decodes DSD64/128 in hardware, which the M9 supports in ISO/DFF/DSF formats.

Eight-layer HDI PCB ensures excellent sound quality

For the first time, in the M9 FiiO uses an eight-layer HDI (High Density Interconnect) PCB with a thickness of only 0.08mm. While the M9 PCB is more complex than the one in the M7, it also allows more components to be integrated into a smaller space, leading to a smaller PCB and a smaller device overall. Combined with the fact that the M9 PCB is L-shaped, similar to modern smartphones, and you have a recipe for outstanding sound quality.

The two AK4490EN DACs employed in the M9 feature a high signal-to-noise ratio, exceptional dynamic range, and low distortion – making for a precise yet exciting sound signature.

Dual AK4490EN DACs for superb decoding performance

The M9 uses Bluetooth 4.2 and supports virtually all Bluetooth formats including the high-resolution ones for your ultimate listening pleasure, including: 24-bit aptX HD (also backwards compatible with aptX), LDAC, and HWA.

Bluetooth audio unleashed with full format support

As a Bluetooth transmitter: LDAC/aptX/aptX HD/SBC (both natively from the player and through USB DAC)

As a Bluetooth receiver: SBC (LDAC to be added with software updates)

The TI OPA1612 is used as the LPF, while the TI OPA1622 serves as the current buffer. To achieve single-ended and balanced output, there are two OPA1622 op-amps used that provide up to 77mW* of power under a 300Ω load.

Specially-designed audio circuit with balanced and single-ended outputs

*Under balanced output

USB audio and coaxial out support

The M9 supports USB audio out (send digital audio bits through USB), with even support for DoP/D2P. Also, the M9 is one of the few players that can receive Bluetooth audio and output it through coaxial (SPDIF) out.

*You can select between USB Audio DoP/D2P in the settings menu

LG IPS touchscreen with in-cell technology

Adorning the front of the M9 is a vibrant, clear 3.2 inch IPS screen capable of 16 million colors and supporting 5-point touch. This IPS screen allows you to easily operate your device with its ability to show even the finest of details.

Be accepting of all music with 2TB of storage

The M9 comes with a healthy 2GB of storage, but the storage can be expanded up to a massive 2TB with micro-SD card!
